Used DEMAG ERGOtech system 350-80

Producer

DEMAG

Type

ERGOtech system 350-80

Year

1997

Clamping unit

Clamping force

35 ton

Opening stroke

350 mm

Distance between tie bars

320 x 320 mm

Mould height min.

180 mm

Platen size (h x v)

460 x 450 mm

Injection unit

Screw diameter

18 mm

Injection volume

23 cm³

Shot weight

20 g

Injection pressure

2868 bar

Measurements and weight

Dimensions

3,3 x 1,2 x 2,0 m

Machine weight

2700 kg
